尺寸毫米(长、宽、高):

Size/mm (length, width, height):

L：2.5~8.0、W：2.0~8.0、H：1.0~4.0

L:2.5~8.0, W:2.0~8.0, H:1.0~4.0

电感范围:047~680uH

Inductance range: 047~680uH

产品介绍:NR系列功率电感，合金铸模绕线式电感系表面黏著式晶片，具极低直流电阻及薄型化元件高度。

Product description: NR series power inductors, alloy mold winding inductor system surface adhesive chip, with very low DC resistance and thin element height.

于大电流使用下感量变化表现稳定，具有优异的表现，所以适用于DC-DC转换器。

The inductance changes steadily and has excellent performance under high current, so it is suitable for DC-DC converter.
